模切机主要技术参数
机型 | Model | 320II/350II | 420II/450II |
模切速度 | Die Cutting Speed | 20-300次/分 | 20-300次/分 |
放卷最大直径 | Max Dia. Of Unwinding | 500mm | 500mm |
卷筒纸最大宽度 | Max Width | 320mm/350mm | 420mm/450mm |
模切最大宽度 | Max Width of Die Cutting | 320mm/350mm | 420mm/450mm |
模切最大长度 | Max Length of Die Cutting | 320mm/350mm | 420mm/450mm |
定位精度 | Fixing Precision | ±0.10mm | ±0.10mm |
总功率 | Total Power | 5kw | 6.5kw |
电源电压 | Voltage | 220v/380v±10% | 220v/380v±10% |
整机重量 | Weight | 1800kg | 2300kg |
外形尺寸 | Overall DImension | 2700×950×1400mm | 2700×1200×1400mm |
性能特点 Functional characteristics
该机是自动模切机的配套产品,此机适用用于窄幅纸张分切。它具有自动计米、计数,设定长度自动停机,放卷由光电自动纠偏控制等功能,整机结构紧凑、速度快、效率高、分切准确。操作简单、运行平稳等特点。
LX-320 type automatic siltting machine that is applicable to slit stenotopic paper is a completes set of product for auto die cutting machine.It has the functions such as auto calculator dial,set length, auto stoppage,and photo-electric to control the feeging.It is characterized by tight construction,fastness,high efficiency,accurate in slitting,rasr of operation and stability in operation.
